Trade-Wind L7200 Series 36" Outdoor Ventilation Hood - L7236-12

Trade-Wind L7200 Series 36" Outdoor Ventilation Hood - L7236-12

This 36-inch Trade-Wind outdoor hood insert features halogen lighting, heavy gauge commercial stainless steel brush finish and dishwasher safe stainless steel baffle filters.

Features:

  • Pyramid BBQ Hoods are 15" deep at top, 32" deep at bottom
  • Matching Telescopic Stainless Steel Duct Covers are available for up to 12' ceilings
  • Design of the Stainless Steel Commercial Baffle Filters adds a Professional Image
  • Telescopic Duct Cover (2-piece) Provided for adjustment up to 10' ceilings
  • Generously proportioned 32" depth of hood provides an Exceptional Capture Area
  • Heavy gauge commercial stainless steel (#304 grade with #4 brush finish)
  • Four 12" by 14" baffle filters for Enhanced Performance (six or eight filters on larger models)
  • Dimmable 50 watt halogen lights
  • Optional In-line Blower(s) Deliver 1266 CFM
  • Remote blower models are pre-wired for use with most in-line or exterior blowers
  • Hoods with internal blowers are all pre-wired and ready for installation
  • Top 10" Round Discharge Only (for rear discharge, use a 10" 90 degree elbow, not provided)
  • Durable, dishwasher safe commercial stainless steel baffle filters
  • All stainless steel exterior design is Easy to keep Clean and Eliminates grease traps

Specifications:

Airflow: 1200 CFM
Blower Included: Yes
# of Speeds: 3
Lights: Dimmable 50W Halogen Lights
Filter: Dishwasher Safe Stainless Steel Baffle Filters
Construction: 304 Stainless Steel
Warranty: 3 Year Limited

Dimensions:

Height: 8"
Width: 36"
Depth: 32"
Weight: 137 lb.

Documents:

Installation / User Manual: Link
Spec Sheet: Link
$2,681.66
Trade-Wind L7200 Series 36" Outdoor Ventilation Hood - L7236-12ā€”
$2,681.66

Product Information

Shipping & Returns

Description

This 36-inch Trade-Wind outdoor hood insert features halogen lighting, heavy gauge commercial stainless steel brush finish and dishwasher safe stainless steel baffle filters.

Features:

  • Pyramid BBQ Hoods are 15" deep at top, 32" deep at bottom
  • Matching Telescopic Stainless Steel Duct Covers are available for up to 12' ceilings
  • Design of the Stainless Steel Commercial Baffle Filters adds a Professional Image
  • Telescopic Duct Cover (2-piece) Provided for adjustment up to 10' ceilings
  • Generously proportioned 32" depth of hood provides an Exceptional Capture Area
  • Heavy gauge commercial stainless steel (#304 grade with #4 brush finish)
  • Four 12" by 14" baffle filters for Enhanced Performance (six or eight filters on larger models)
  • Dimmable 50 watt halogen lights
  • Optional In-line Blower(s) Deliver 1266 CFM
  • Remote blower models are pre-wired for use with most in-line or exterior blowers
  • Hoods with internal blowers are all pre-wired and ready for installation
  • Top 10" Round Discharge Only (for rear discharge, use a 10" 90 degree elbow, not provided)
  • Durable, dishwasher safe commercial stainless steel baffle filters
  • All stainless steel exterior design is Easy to keep Clean and Eliminates grease traps

Specifications:

Airflow: 1200 CFM
Blower Included: Yes
# of Speeds: 3
Lights: Dimmable 50W Halogen Lights
Filter: Dishwasher Safe Stainless Steel Baffle Filters
Construction: 304 Stainless Steel
Warranty: 3 Year Limited

Dimensions:

Height: 8"
Width: 36"
Depth: 32"
Weight: 137 lb.

Documents:

Installation / User Manual: Link
Spec Sheet: Link
